MINI-RESTER 1/2MIP (NO LEAD)

MINI-RESTER 1/2MIP

• Arrester chamber: 304 Stainless steel
• Type L copper tube
• Connection fitting: Brass
• Piston: Polypropylene with EPDM o-rings

WORKING LIMITS
Max working temperature: 250º F
Max working pressure: 350 psig
Note: PEX and CPVC connection specifications are limited to those called out in their respective ASTM Standards for Fittings (CPVC D2846, PEX F1807 & F1960).

INSTALLATION NOTES
Approved for installation at any angle. No access panels required.
Solder any sweat connections - DO NOT BRAZE.

Sweat connections are compatible with Press or Push fittings

CERTIFICATIONS/APPROVALS
Complies with Uniform Plumbing Code (UPC), National Plumbing Code of
Canada, International Plumbing Code (IPC). Conforms to ASSE 1010.
